380V 50Hz 10.6kw 15Tの耐久力のあるもみ米のドライヤー

380V 50Hz 10.6kw 15T Wear Resistant Paddy Rice Dryer

商品の詳細:

起源の場所:	中国
ブランド名:	NEWBELT
証明:	ISO900/CE
モデル番号:	5HM-15

お支払配送条件:

最小注文数量:	1
価格:	negotiation
パッケージの詳細:	木箱
受渡し時間:	私達があなたの沈殿物を受け取った10日後
支払条件:	T/T、ウェスタン・ユニオン、MoneyGram
供給の能力:	200Sets/month

接触

詳細製品概要

製品名:	水田の販売のためのより乾燥したムギの種トウモロコシの水田のトウモロコシの米の穀物乾燥機	モデル:	5HM-15
容量（kg）:	15トン	次元 LWH （mm）:	4320×2492×10370
純重量:	4,200kg	熱源:	生物量の炉/ガス・バーナー/ディーゼルバーナー
パワー消費量（kw）:	10.6
ハイライト:	Wear Resistant Paddy Rice Dryer , 15T Paddy Rice Dryer , 10.6kw Rice Paddy Dryer

Paddy Dryer Wheat Seed Corn Paddy Maize Rice Grain Dryer For Sale

1. One machine multi-purpose, can dry rice, wheat, corn, peanuts, soybeans.Sorghum and other food crops and their seeds.

2. Forced dispersing device and quantitative feeding cycle of positive and negative grain discharge, thin layer and large air flow, uniform grain drying, high drying efficiency.

3. Low temperature drying, good quality rice, high germination rate of seeds.

4. Adopt large spiral feeder, high strength nylon dustpan, stainless steel net plate, wear-resisting, anti-deformation, durable and don't hurt grain.

5. Residual material cleaning device, easy to remove grain residual material, prevent mixing.

TECHNICAL PARAMETERS

Product Description
Model		5HPX-15	5HPX-20	5HPX-30	5HPX-30B	5HPX-35
Model		5HPX-15	5HPX-20	5HPX-30	5HPX-30B	5HPX-35
Loading capacity(kg)	Paddy	3,000~15,000	3,000~20,000	4,000~30,000	4,000~30,000	5,000~35,000
	Corn	3,800~18,500	3,800~24,600	5,000~36,400	5,000~36,400	6,000~42,000
Dimension LWH (mm)		4321258310000	4600326310500	4600326012700	4600357012700	5712500012400
Net Weight		3,000	4,200	5,500	6,500	8,000
Heat Source		Biomass Furnace/Gas Burner/Diesel Burner
Power Consumption (kw)		9.95	10.6	15.45	21.7	19.7
Input Voltage		3 Phase 220V/380V,50Hz
Husk Furnace	Type	Indirect
	Ignition	Manual
Function	Loading	50~60(approx)	50~60(approx)	60~70(approx)	60~70(approx)	60~70(approx)
	Discharge	50~60(approx)	50~60(approx)	60~70(approx)	60~70(approx)	60~70(approx)
	Drying Rate	0.5-1.2 %/h	0.5-1.2 %/h	0.6-1.2 %/h	0.6-1.4 %/h	0.5-1.2 %/h
Standard Devices		Online moisture meter, Conveyor ,Discharge system, Buffer system, Elevator ,Suction fan, Temperature sensor
Safety Devices		Overload device, Temperature control device, Control fuse, Leakage protection device, Air pressure switch

Furnace Burner Options

Furnace Type	Yes/No
Diesel	Yes
Gas	Yes
Coal	Yes
Biomass Material	Yes(Husk/Wood/Straw/Etc)

FEATURES:
1. Professional use grain dryers which are designed especially for small pack and quality rice. Bring you the highest profit and income.
2. Spreading device and rotary valves ensure seeds and grains to circulate evenly and make even drying possible
3. Use giant screw conveyor, PVC steel bucket,Galvanized steel sheet for durability use.
4. Sufficient Inspection zone and emergency unloading valve to make sure no stuck for the grains in the dryer

Drying Unit Diagram

20 Tons Capacity Double Centrifugal Fan Grain Dryer Machine Fuel Saving Type 1

What We Can Offer

1)Whole turnkey project solution
included Pre-cleaning machine,elevator,input&outlet pipe,furnace and dryer
2)Plant designition service
supply you all the possibly area required,the instllation diagram for consideration
3)Instllation and commisioning service
professional engineer woud guide you for the assembling and commisioning the machine
4)Full time online service
24 hours online technique service,ensure to tackle the problem immediately
5)Enormous spare parts to support
easy broken spares and wearing parts would be send timely,no worry for drying season

380V 50Hz 10.6kw 15Tの耐久力のあるもみ米のドライヤー 2

380V 50Hz 10.6kw 15Tの耐久力のあるもみ米のドライヤー 7

Applicantion:

380V 50Hz 10.6kw 15Tの耐久力のあるもみ米のドライヤー 8
